Powered Dolly Applications
The TrailercaddyHD Powered Trailer Dolly is designed for moving king pin and covered equipment trailers, as well as campers up to 20,000 lbs. The TrailerCaddy powered dolly has a 3000 lbs hydraulic lift kit designed to lift up king pin, ball, or pintle hitch type of trailer connections. The most common environment requiring a TrailerCaddy are RV and camper dealerships, military bases, and vehicle maintenance locations at government repairs centers. Use the Powered Trailer Mover where constant movement of king pin wheeled equipment in areas typically too confined for conventional fork trucks or large tow vehicles. The TrailerCaddy power, size, and price tag make it a more effective and affordable alternative or risking a possible injury from employees strong-arming the equipment.
The powered trailer dolly is less bulky than the traditional electric trailer puller product, which results in fewer accidents and lower maintenance costs. Increased control over the trailer mover in tightly confined areas also causes minimal damage to surrounding parts and equipment compared to other electric puller products.
Powered Dolly Video
Powered Dolly Features and Specifications
1.The TrailerCaddyHD comes standard with a 36-volt system, 3 12-volt batteries, designed to give the operator 16-hours of continuous use, without moving a cart, before recharging. Plenty of battery life to usually last two shifts.
2.The mover has a variable speed twist grip for forward and reverse cart directions from 0 to 2 mph. The ergonomically correct variable speed feature prevents carpal tunnel and allows the operator to maintain smooth control while intricately maneuvering the cart. The TrailerCaddyHD Chain Drives ability to go 2 mph allows the Battery Powered Trailer Mover machine to keep up with the operator without frustration from waiting for a slowly operating machine when operating the unit from point A to B through-out your facility
3.The safety stop switch positioned at the back of the handle bar box immediately stops the mover when depressed to prevent any possible injury from operating the device and pulling a cart. This feature is a must when buying any piece of equipment.
4.The electric lift option and customized attachment prevent you from having to fabricate multiple attachments on everyone of your carts or equipment. The TrailerCaddyHD Chain Drive Battery Powered Mover arm lowers and raises for attaching firmly to the bottom of your cart. Weight is transferred from your cart to the front drive wheels of the mover for better traction when moving your load.
5.The TrailerCaddy is designed for easy maneuvering and pivoting of your loads. After the arm is attached firmly to your carts or equipment, the unit can pivot a full 180 degrees under the arm. This feature allows for turning your loads a full 90 degrees without jack knifing your cart or manually turning the front of you load.
Standard TrailerCaddy Features
•Heavy Duty Steel Frame
•2000 lb. Differential / Transaxle
•High Tech Speed Controller
•Neutral Throttle Braking
•3000 lbs Hydraulic Actuator Lift Kit
•36v(3) 105 Amp Batteries
•Variable Speed Twist Grip
•0-3 mph Forward/ Reverse
•Battery Discharge Indicator
•Safety Stop Switch
•Non-Marking Foam Filled Tires
•Ball Hitch and Steel Mounting Bracket
•Maintenance-free batteries (set of 3)
•Flashing Light and Pole
